3 Inch Hydraulic Hose Crimping Machine with 1000T Crimping Force 31.5MPA Rated Pressure and 6-76mm Crimping Range

3 Inch Hydraulic Hose Crimping Machine with 1000T Crimping Force 31.5MPA Rated Pressure and 6-76mm Crimping Range

Nama merek:	FY
Nomor Model:	TA-CBK-120C
MOQ:	1 set
harga:	5000
Ketentuan Pembayaran:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Kemampuan Penyediaan:	300 set per bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Shanghai, Cina

Sertifikasi:

Dokumen:

OUR CATALOGUE.pdf

Berat:

1250kg

Kondisi:

BARU

Dimensi (P*L*T):

755*1045*1630MM

Jaminan:

1 tahun

Layanan purna jual disediakan:

Dukungan teknis video, dukungan online

Voltase:

110V/220V/380V/415V 50/60Hz

Kekuatan (w):

5,5kW

Kekuatan crimping:

1000T

Warna:

Biru / putih atau kustom

Jangkauan crimping:

6-76mm,1/4"hingga 3'',1/4''-3''

Nama Produk:

Systerm Kontrol Tombol 3 Inci 15 Mati dengan Alat Cetakan Perubahan Cepat Mesin Crimping Selang Hidr

Aplikasi:

Selang keriting

Dies gratis:

15 Set

Tekanan Dinilai:

31.5mpa

Kata kunci:

Mesin crimping selang hidrolik PLC

Menyorot:

Mesin Press Selang 3 Inch, Mesin Press Selang Spiraled, mesin press pipa selang

Kemasan rincian:

Ekspor Kotak Kayu Standar

Menyediakan kemampuan:

300 set per bulan

Menyoroti:

1000T Crimping Force Hydraulic Hose Crimping Machine

31.5MPA Rated Pressure Hose Pressing Machine

6-76mm Crimping Range Hydraulic Fitting Press

Deskripsi Produk

3 Inch Button Control System 15 Dies With Fast Change Moulds Tools Hydraulic Hose Crimping Machine

Hydraulic Hose Pressing Machine with Button Control System

Introducing our 3 Inch Hydraulic Hose Pressing Machine, engineered for high efficiency and quick operation. Designed for precision and versatility, this machine is perfect for various industrial applications.

Key Features

High Output of 300 Pieces/Hour - Designed for rapid crimping to boost productivity
Button Control System - Intuitive interface for precise operation
Fast Change Mould Tools - Quick-change moulds for seamless transitions
Versatile for Big Elbow Fittings - Handles larger hydraulic fittings with ease
Robust Construction - Built for durability and long-term reliability
Safety Features - Designed with operator safety in mind

Operation Precautions

Perform 20-30 unloaded crimps when first using the machine
In winter, perform additional unloaded crimps to increase oil temperature
Select and install appropriate molds based on hose specifications
Position hose with joint properly for complete crimping
Execute crimping operation until automatic mold opening
Verify crimped dimensions and adjust micrometer as needed

Technical Specifications

Crimping Range	6-76mm (1/4"-3" inner diameter)
Quantity of Dies	13 sets
System Pressure	31.5Mpa
Motor Power	4kw
Voltage Options	110V/220V/380V/415V, 50HZ/60HZ
Crimping Force	2800KN
Work Efficiency	300pcs/h
Machine Dimensions	840×1090×1760mm
Net Weight	1250kg
